The plant is using proven Danieli Olivotto Ferrè technology to homogenize aluminium alloy slabs, treating 500x1,650-mm slabs in lengths up to 8 m, at an overall yearly output up to 24,000 tons/year.
Heating and soaking in two homogenizing furnaces and cooling in a cooling chamber are performed in continuous mode.
Furnace equipment and process controls perform in automatic mode, in a controlled atmosphere, matching the stringent AMS 2750E standard for aerospace markets. The subsequent slab cooling treatment delivers perfect quality in terms of mechanical/metallurgical properties.
Excellent results achieved for 140-ton, 500x1,650x7,600-mm aluminium slabs include:
> 1st target temperature achieved, 440°C in 11 hrs.;
> 1st holding duration, 4 hrs. at. 440°C;
> Temperature uniformity achieved, ±5°C (as per AMS 2750E);
> 2nd target temperature achieved, 470°C in 4.5 hrs.;.
> 2nd holding duration, 24 hrs. at 470°C;
> Temperature uniformity achieved ±5°C (as per AMS 2750E).
Fuel and power consumption during the cycle have been maintained under the specified limit.
The plant is in industrial operation after a smooth commissioning sequence and final acceptance.a
